Sturdy cast base ensures stable and efficient operation of the mill;
High standards of safety and sanitation, food-grade stainless steel for the parts contacted with materials;
Swing out feeding module ensures easy access for cleaning and complete material discharging;Integral assembly and disassembly of the grinding roller set ensures quick roll change, reducing downtime;Photoelectric level sensor, stable performance, less affected by material properties and environmental factors, easy to realize digital control;
Grinding roll disengaging monitoring system with position sensor, avoiding roller grinding each other when no material;Grinding roller speed monitoring,monitor the operation of tooth wedge belt by speed monitoring sensor.
|
Model |
Length (L)/mm |
Width (W)/mm |
Height (H)/mm |
Weight (kg) |
|
PLMFY 100×25 |
1834 |
1496 |
1718 |
2900 |
|
PLMFY 125×25 |
2084 |
1496 |
1718 |
3400 |
|
PLMFY 150×25 |
2334 |
1496 |
1718 |
3900 |
|
PLMFY 100×25×4 |
1964 |
1496 |
2258 |
5100 |
|
PLMFY 125×25×4 |
2214 |
1496 |
2258 |
6000 |
|
PLMFY 150×25×4 |
2464 |
1496 |
2258 |
6900 |
|
PLMFY 100×30 |
1834 |
1696 |
1718 |
3460 |
|
PLMFY 125×30 |
2084 |
1696 |
1718 |
3960 |
